Batch cracking equipment

Batch cracking equipment:

Hengze indirect heating treatment technology is to heat solid waste in the absence of oxygen to vaporize the liquid phase components to achieve solid-liquid separation, and collect and recover the liquid phase through condensation purification process to achieve oil recovery and sewage purpose of reuse. The recovered oil can be used as fuel base oil, the water phase is reused as the system circulating water, and the solid phase is harmless. The main features of the standard cracking equipment:

Safety - 4+ safety protection system, automatic monitoring system.

Health - anaerobic indirect heating, 0 chemicals added, no dust.

Stable—Self-cleaning technology ensures stable operation when dealing with viscous materials.

Effect - good flue gas control system and waste heat recovery system improve thermal efficiency by more than 35%.

Economical—recovers the oil phase in the waste, and the TBH recovery rate is over 95%.

Environmental protection - solid phase, liquid phase and gas phase discharge after treatment, all reach a good level.

1. The internal system of the equipment system operates under normal pressure, which can prevent gas leakage, and the process is more environmentally friendly

2. The horizontal double-drive rotary structure design of the cracking equipment, the equipment is heated more evenly, and the service life is longer

3. Special process design, effectively remove corrosive gas, reduce equipment corrosion damage and air pollution

4. The special structure of the air outlet of the equipment avoids blockage and is safer

5. The internal structure of the innovative multi-stage separator device can effectively separate the generated gas and the entrained colloid, and reduce the possibility of blockage of the corrosion system of the equipment system

6. Automatic feeding and slag discharge system, shortening the time of near feeding and discharging, saving labor, reducing costs and improving production efficiency

7. The new counter-current wet dust removal process makes the exhaust gas and dust treatment fully meet the emission standards

8. The new condensing system solves the problem of easy blockage of the condensing pipe

9. Brand new design, more refined equipment, less land occupation, higher oil yield, more environmental protection and safety
